N9010B EXA 信號分析儀，多點觸控，10 Hz 至 44 GHz
EXA X-Series Signal Analyzer, Multi-touch N9010B
This configuration guide will help you determine which performance options, measurement applications, accessories, and services to include with your new multi-touch EXA or to add as upgrades to an existing EXA.
主要特性和功能
使用快速、靈活的 EXA 應對各種需求
獲得對毫米波測量結果高效的分析
利用優異的電平精度、DANL 和 TOI，探測大信號遮蔽下的最小信號
使用列表掃描模式，在不連續的頻率點上快速執行功率測量
X 系列測量應用軟件可以簡化測試
選件
Frequency Range
N9010B-503 Frequency Range, 10 Hz to 3.6 GHz
N9010B-507 Frequency Range, 10 Hz to 7 GHz
N9010B-513 Frequency Range, 10 Hz to 13.6 GHz
N9010B-526 Frequency Range, 10 Hz to 26.5 GHz
N9010B-532 Frequency Range, 10 Hz to 32 GHz
N9010B-544 Frequency Range, 10 Hz to 44 GHz
Preamplifier
N9010B-P03 Preamplifier, 3.6 GHz
N9010B-P07 Preamplifier, 7 GHz
N9010B-P13 Preamplifier, 13.6 GHz
N9010B-P26 Preamplifier, 26.5 GHz
N9010B-P32 Preamplifier, 100 kHz - 32 GHz
N9010B-P44 Preamplifier, 100 kHz - 44 GHz
Bandwidth
N9010B-B40 Analysis Bandwidth, 40 MHz
Performance Options
N9010B-DP2 Digital Processor, 2 GB Capture Memory
N9010B-EA3 Electronic Attenuator, 3.6 GHz
N9010B-EDP Enhanced Display Package License
N9010B-EMC Basic EMC Functionality
N9010B-FP2 Fast Power, up to 40 MHz Bandwidth
N9010B-FSA Fine Resolution Step Attenuator
N9010B-MPB Microwave Preselector Bypass
N9010B-PFR Precision Frequency Reference
N9010B-TDS Time Domain Scan
N9010B-NF2 Noise Floor Extension
Calibration Options
N9010B-A6J ANSI Z540-1-1994 Calibration
N9010B-AMG Calibration + Uncertainties + Guardbanding (Accredited)
N9010B-UK6 Commercial Calibration Certificate With Test Data
Connection Options
N9010B-CR3 Connector, Widebａnd IF Output
N9010B-CRP Connector, Programmable Rear IF Output
N9010B-YAS Y-Axis Output
External Mixing
N9010B-EXM External Mixing
Portable packaging
N9010B-PRC Portable Configuration
Security - PC features
N9010B-SF1 Security Features, Exclude Launching Programs
N9010B-SF2 Security Features, Prohibit Saving Results
N9010B-SSD Additional Removable Solid State Drive
Source Connectivity
N9010B-ESC External Source Control License
Accessories
1CM113A Rack mount flange kit 177.0mm H (4U) - two flange brackets, 2015 color
1CN103A Handle kit 177.0mm H (4U) - two front handles, 2015 color
1CP105A Rack mount flange and handle kit 177.0mm H (4U) - two brackets and front handles
1DVR001A ROM/CD-R/RW drive
1KBD001A USB keyboard-smaller keyboard
1MSE001A Mouse
MLP001A Minimum loss pad, 50 to 75 ohm
1CR013A Rack Slide Kit for 11in, 14in, and 16in Mounting Holes
Additional Documentation
N9010B-AB1 Korean localization, user interface and getting started guide
N9010B-AB2 Chinese localization, user interface and getting started guide
N9010B-ABE Spanish localization, user interface and getting started guide
N9010B-ABF French localization, user interface and getting started guide
N9010B-ABJ Japanese localization, user interface and getting started guide
N9010B-AKT Russian localization, user interface and getting started guide
